Spesifikasi FATEK FBs-60XYR
Parameter Spesifikasi
Jenis Modul ekspansi digital I/O
Seri FATEK FBs PLC
Total I/O
Digital input 36 titik
Tegangan input 24 VDC ±10%
Tipe input Dapat digunakan untuk sensor NPN/SINK atau PNP/SOURCE
Kecepatan input Low-speed, sekitar 4,7 ms
Digital output 24 titik relay
Kapasitas kontak relay Maksimal 2 A per titik; 4 A per common
Tegangan beban Maksimal 250 VAC atau 30 VDC
Beban induktif Maksimal 80 VA AC / 24 VA DC
Respons relay Sekitar 10 ms
Isolasi output Elektromagnetik, 1.500 VAC selama 1 menit
Indikator LED untuk setiap input dan output
Power supply Built-in; tersedia versi AC dan DC
Versi AC FBs-60XYR-AC: 100–240 VAC
Versi DC FBs-60XYR-D24: 24 VDC
Dimensi Sekitar 175 × 90 × 80 mm
Pemasangan Sisi kanan CPU/modul FBs, DIN rail
Pemrograman Mengikuti CPU utama FATEK FBs melalui WinProLadder
Negara produksi Made in Taiwan

Daftar Lengkap FATEK FBs Digital I/O Expansion
Kapasitas 60 titik
Tipe Input Output Power supply
FBs-60XYR 36 DI 24 relay Dari expansion bus
FBs-60XYT 36 DI 24 transistor NPN/SINK Dari expansion bus
FBs-60XYJ 36 DI 24 transistor PNP/SOURCE Dari expansion bus
FBs-60XYR-AC 36 DI 24 relay Built-in 100–240 VAC
FBs-60XYT-AC 36 DI 24 transistor NPN Built-in 100–240 VAC
FBs-60XYJ-AC 36 DI 24 transistor PNP Built-in 100–240 VAC
FBs-60XYR-D24 36 DI 24 relay Built-in 24 VDC
FBs-60XYT-D24 36 DI 24 transistor NPN Built-in 24 VDC
FBs-60XYJ-D24 36 DI 24 transistor PNP Built-in 24 VDC
Expansion unit dengan built-in power supply
Kapasitas Relay Transistor NPN Transistor PNP
24 titik: 14 DI + 10 DO FBs-24XYR-AC / D24 FBs-24XYT-AC / D24 FBs-24XYJ-AC / D24
40 titik: 24 DI + 16 DO FBs-40XYR-AC / D24 FBs-40XYT-AC / D24 FBs-40XYJ-AC / D24
60 titik: 36 DI + 24 DO FBs-60XYR-AC / D24 FBs-60XYT-AC / D24 FBs-60XYJ-AC / D24
Expansion module tanpa built-in power supply
Tipe Jumlah I/O Keterangan
FBs-8X 8 DI Digital input 24 VDC
FBs-20X 20 DI Digital input 24 VDC
FBs-24X 24 DI High-density input
FBs-4YR / 4YT / 4YJ 4 DO Relay / NPN / PNP
FBs-8YR / 8YT / 8YJ 8 DO Relay / NPN / PNP
FBs-16YR / 16YT / 16YJ 16 DO Relay / NPN / PNP
FBs-24YT / 24YJ 24 DO High-density NPN / PNP
FBs-8XYR / 8XYT / 8XYJ 4 DI + 4 DO Kombinasi digital I/O
FBs-16XYR / 16XYT / 16XYJ 8 DI + 8 DO Kombinasi digital I/O
FBs-24XYR / 24XYT / 24XYJ 14 DI + 10 DO Kombinasi digital I/O
FBs-40XYR / 40XYT / 40XYJ 24 DI + 16 DO Kombinasi digital I/O
FBs-60XYR / 60XYT / 60XYJ 36 DI + 24 DO Kombinasi digital I/O
Expansion power supply
Tipe Input power
FBs-EPW-AC 100–240 VAC
FBs-EPW-D24 24 VDC
Arti kode:
X = digital input 24 VDC.
Y = digital output.
R = relay output.
T = transistor NPN/SINK.
J = transistor PNP/SOURCE.
AC = built-in power supply 100–240 VAC.
D24 = built-in power supply 24 VDC.
